Cold Spraying Equipment

The following is the introduction of high quality cold spraying equipment, hoping to help you better understand cold spraying equipment.Suzhou Airico Machinery Equipment Co., Ltd. is a technology innovation enterprise specializing in equipment manufacturing and research and development. It is one of the few domestic manufacturers that can independently produce arc spraying equipment, plasma spraying equipment, and supersonic spraying equipment.

Send Inquiry

Product Description

The Airico-M3 cold spraying equipment is touch screen operated. The equipment design structure adopts a fully closed-loop automatic control structure. All gases are controlled by imported pressure sensors and imported pressure regulating valves. The pressure can be monitored in real time to automatically reach the process set value. The fuel used is propane and the combustion aid is air. It is a very stable combustion mode among gas engines on the market. The spray gun structure is designed according to the principle of rocket generators. The flame flow speed reaches more than 2000m/s, the output power is large and can be adjusted steplessly. The spray gun adopts axial center powder delivery. This new injection method allows the powder to be better dissolved and evenly distributed throughout the flame, improving the coverage efficiency and coating quality. It has a process formula storage and call function, and parameters can be added, modified, and saved. The system fuel adopts a fully closed-loop design, modular design, high-performance PLC control, stable and easy operation; the prepared coating has excellent performance, with a low porosity of less than 1% (average porosity less than 0.5%), and a spraying efficiency of 30KG powder per hour.

Airico-M3 cold spraying equipment system

Cold Spraying Equipment

The Airico-M3 cold spray control system has advanced levels compared to similar foreign products, with superior performance and easy operation. It can achieve fully digital operation of the spraying process, and real-time monitoring of the spraying parameters of the system, which can immediately respond to system failures.

Airico-M3 Basic parameters of cold spraying equipment

Number	Project	Basic parameters
1	Control type	Touch screen+MFC mass flow meter+Siemens PLC control
2	Rated power	550W
3	Supply Voltage	AC 220V；50Hz
4	Work environment	Indoor, room temperature
5	Kerosene pressure/flow rate	1.2Mpa15~24L/h
6	Oxygen pressure/flow rate	1.6Mpa800-1100L/h
7	External dimensions of control cabinet	500×1050×1364mm
8	Control cabinet weight	80Kg

Powder feeder

Cold Spraying Equipment

This type of powder feeder adopts foreign technology, upgrades the control system, and is convenient for cleaning powder. The main gas of the spray gun is used as the powder feeding gas. The sprayed powder is transported to the outlet of the powder feeder through the rotation of the porous powder feeding tray. The powder leaves the powder feeding bucket together through the gas pressure and enters the spray gun. The speed of the servo motor on the touch screen is adjusted to adjust the powder feeding amount.

Powder feeder parameter table

Number	Project	Basic parameters
1	Powder delivery method	Scraper pneumatic type
2	Double tube capacity	3.0L
3	Powder gas delivery	Nitrogen or argon
4	Gas pressure for powder delivery	0.4-1.2MPa
5	Powder feed rate	0~160g/min
6	Powder delivery accuracy	±1%
7	Powder delivery gas flow rate	0-25L/min
8	External dimensions of powder feeder	900×450×1650mm
9	Weight of powder feeder	50Kg

Imported propane vaporizer

Cold Spraying Equipment

Vaporizer Type/Model	Indirect丨Dry-Electric丨Feed Out
	Model	Z25	Z40	Z50	Z100	Z150
Hazardous Area Classification		Class I, Division 1, Group D,T3; Ex d IIA T3 Gb
Approvals		UL/ULc,CE(ATEX &IECEx),PED(SEP)
Vaporization Capacity	Kg/hr	25	40	50	100	150
	US Gal/hr	12.5	20	25	50	75
	MMBTU/hr	1.1	1.8	2.2	4.5	6.8
Liquid Inlet Connection		1/2" FNPT	1/2"FNPT	1/2" FNPT	3/4"FNPT	3/4" FNPT
Vapor Outlet Connection		1/2" FNPT	1/2" FNPT	1/2"FNPT	3/4"FNPT	3/4"FNPT
Design Pressure (MAWP)		250 psig-17.2 barg
Relief Valve Set Point		250 psig-17.2 barg
Hydrostatic Test Pressure		375 psig-25.9 barg
Unit Dimensions		26.7"Lx9.5"Hx8.3"W			67.2"Lx9.5"Hx8.3"W
		677mmLx241mmHx210mmW			1706mmLx241mmHx210mmW
Shipping Dimensions		34" Lx 11"H x 14" W			75"Lx 11" H x 14" W
		863mmLx280mmHx356mmW			1905mmLx280mmHx356mmW
Shipping Weight		55 lb/25 Kg			145 lb/66 Kg
Optional Accessories		Tank Mount Kit; Tank Mount Piping Kit; Wall Mount Kit;Strainer and Piping			Floor Mount Kit;Wall Mount Kit,Strainer and Piping Kit;Regulator/Gauge Kit;Drain Valve Kit

Airico-M3 Supersonic air equipment Spray gun

Cold Spraying Equipment

The Airico-M3 spray gun uses propane as fuel, air as combustion and cooling gases, and nitrogen for powder feeding; The spray gun can work continuously and stably for a long time.

Airico-M3 Basic parameters of spray gun

Number	Project	Basic parameters
1	Flame speed	2100m/s
2	Cooling method	Air cooling
3	Coating porosity	0.1%--0.3%
4	Bond strength	>85MPa
5	Suitable powder size for spraying	10-45um
6	Work environment	Fireproof and ventilated soundproof room
7	Spray gun external dimensions	80mm×90mm×300mm

Airico-M3 cold spraying equipment auxiliary air pipe

Cold Spraying Equipment
